Magnetic Float Ball for Level Controller

Magnetic Float Ball for Level Controller-45*145 This product is similar to the previous 50 * 210 level gauge float, with a smaller size and polished finish. The pressure is also produced according to customer requirements, and the appearance is more beautiful. In order to increase the pressure resistance of the float ball, the old level gauge float ball has ring reinforcement on the ball body. In fact, it is incorrect to have ring reinforcement on the ball body. Wearing ring reinforcement does not increase pressure, but instead makes it easier for the float ball to sink on the ring reinforcement due to excessive pressure, making it unable to work better. After completing the integrated treatment, we reinforced the inside of the ball body to make it more resistant to pressure and more aesthetically pleasing.

Testing :

Physical photos：

Feature And Application of Magnetic Float Ball for Level Controller-45*145

Magnetic Float Ball for Level Controller-45*145 it is working in level switch /Level Gauge /Level Gauge magnetic flap .It helps the liquid level gauge achieve water level control balance. When the magnetic levitation ball floats up and down along the pipeline with changes in the liquid level, the magnetic steel inside the levitation ball attracts the reed tube at the corresponding position in the sensor, causing a change in the total resistance (or voltage) of the sensor. Then, the transmitter converts the changed resistance (or voltage) signal into a 4-20mA current signal output. Our XMT series digital control instrument (or DSB type optical column digital display instrument) can be selected to measure the liquid level remotely, and upper and lower limit alarms can be set on the display instrument to achieve positional control of the liquid level. Alternatively, other regulators can form a liquid level constant value adjustment system to achieve continuous PID adjustment of the liquid level.

How to choose a liquid level gauge

For the selection of liquid level instruments, accuracy level and function are also important considerations based on measurement requirements. Users need to choose the accuracy level of the instrument according to the usage situation to achieve economic benefits. For example, when used for trade settlement, product handover, and energy measurement, higher accuracy levels such as 1.0, 0.5, or higher should be chosen; For process control applications, select different accuracy levels according to control requirements; In some cases where only the process flow is detected without the need for precise control and measurement, slightly lower accuracy levels such as 1.5, 2.5, or even 4.0 can be selected. In this case, low-cost plug-in level gauges can be used.

The use of atmospheric storage tank level measuring instruments is relatively simple, mostly using magnetostrictive level gauges/level transformers.
